3 Cylinders 16KW 20KVA Perkins Diesel Generator Set Open Skid
- Place of Origin: CHINA
- Brand Name: ACEPOW
- Certification: CE,ISO, SASO
- Model Number: A03A-22G
- Minimum Order Quantity: 1 PCS
- Price: Negotiate
- Packaging Details: NUDE PACKING,PLYWOOD CASE
- Delivery Time: 25 DAYS
- Payment Terms: L/C, D/P, T/T
- Supply Ability: 10000SETS/YEAR
- Product description
| R.P.M: | 1500 | Out Voltage(v): | 400 |
|---|---|---|---|
| Power Factor: | 0.8 | Cylinders: | 3 |
| Aspiration: | NA | Governor: | MECH |
| Constructive Version: | Open Skid | Dimensions(LxWxH): | 1410x715x1080 |
| High Light: | Open Skid perkins dg set,20KVA perkins dg set,16KW perkins dg set | ||
16KW 20KVA Perkins Diesel Generator Set
| Genset Model: | APP-22 | ||
| Prime Power (kw/kva) | 16/20 | Standby Power(kw/kva) | 18/22 |
| Voltage (v) | 400/440 | Rated Speed (rpm) | 1500 |
| Frequency (Hz) | 50 | Rated Current (A) | 36 |
| Connection: | 3 phase 4 wire | Power Factor: | 0.8 |
| Engine Model: | 404A-22G1 | Alternator Model: | TAL-A40-F |
| Net Weight (kgs)-Open | 551 | Net Weight (kgs)-Silent | 786 |
| Dimensions (mm)-Open | 1410x 715 x1080 | Dimensions (mm)-Silent | 1815x741x1324 |
Our generator advantages:
Stable and reliable performance, convenient service, low consumption, perfect Operability, easy installation and maintenance, a wide range of applications.
Standard Configuration:
Engine: Perkins 404A-22G1
Cooling Fan with fan guard and front guard
Alternator: Single bearing, IP23, H class
24V Charger
Shock Absorber
Dry Air Filter. Dual Fuel Filter. Engine Oil Filter.Coolant Filter.
MCCB Circuit Breaker
Standard Control Panel; ATS for optional
12V Start Battery with connecting cable
Storage Battery and battery line, Exhaust pipe,Corrugated pipe for anti-vibration, Cone Tube,Flange, Muffler
Soundproof Enclosure/Canopy for optionalDocuments
FAQ:
1. What's your power range of diesel generators?
We can offer diesel generators range from 10kva~2000kva.
2. What's your delivery time?
15-30 days after deposit received.
3. What's your payment?
1). 30% T/T deposit advance, the balance paid against the copy of BL.
2). 100% Irrevocable LC at sight.
4. What's your warranty?
One year or 1500 hours which comes first.
5. What's your MOQ?
We accept the MOQ is 1 set.
6. What’s the frequency and voltage of diesel generators?
Voltage Available: 50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client’s request
Prime Power: comply with GB/T2820-97(eqv.ISO8528). Genset can run unlimitedly under certain power range. One hour 10% over load in every 12 running hours is allowed;
Standby Power: standby power is the limit value of maximum output for emergency use. It is off-oil power, overloading is prohibited
7. Can the generators be customized?
Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, inudstrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.
